Friday 31 March 2017

Installing Tomcat on Docker

installing Tomcat on Docker

A different way of looking at running Tomcat is to ignore the cloud platform and install and configure everything inside a docker instance. Rather than picking a cloud instance we are going to run this inside VirtualBox and assume that all of the cloud vendors will allow you to run Docker or configure a Docker instance on a random operating system. What we did was to initially install and configure Oracle Enterprise Linux 7.0 from a iso into VirtualBox. We then installed Docker with the command and start the service
sudo yum install docker
sudo systemctl start docker
We can search for a Tomcat installation and pull it down to run. We find a Tomcat 7.0 version from the search and pull down the configuration
docker search tomcat
docker pull consol/tomcat-7.0

We can run the new image that we pulled down with the commands
docker run consol/tomcat-7.0
docker ps
The docker ps command allows us to look at the container id that is needed to find the ip address of the instance that is running in docker. In our example we see the container id is 1e381042bdd2. To pull the ip address we execute
docker inspect -f format='{{.NetworkSettings.IPAddress}}' 1e381042bdd2
This returns the ip address of 172.17.0.2 so we can open this ip address and port 8080 to see the Tomcat installation.

In summary, this was not much different than going through Bitnami. If you have access to docker containers in a cloud service then this might be an alternative. All three vendors not only support docker instances but all three have announced or have docker services available through IaaS. Time wise it did take a little longer because we had to download an operating system as well as Java and Tomcat. The key benefit is that we can create a master instance and create our own docker image to launch. We can script docker to restart if things fail and do more advanced options if we run out of resources. Overall, this might be worth researching as an alternative to provisioning and running services.
Source:


Wednesday 29 March 2017

Docker


An image is a lightweight, stand-alone, executable package that includes everything needed to run a piece of software, including the code, a runtime, libraries, environment variables, and config files.
container is a runtime instance of an image—what the image becomes in memory when actually executed. It runs completely isolated from the host environment by default, only accessing host files and ports if configured to do so.
Containers run apps natively on the host machine’s kernel. They have better performance characteristics than virtual machines that only get virtual access to host resources through a hypervisor. Containers can get native access, each one running in a discrete process, taking no more memory than any other executable.



















Source:https://docs.docker.com/engine/getstarted/step_four/#step-3-learn-about-the-build-process


Build the app

We are ready to build the app. Make sure you are still at the top level of your new directory. Here’s what lsshould show:
$ ls
Dockerfile  app.py   requirements.txt
Now run the build command. This creates a Docker image, which we’re going to tag using -t so it has a friendly name.
docker build -t friendlyhello .
Where is your built image? It’s in your machine’s local Docker image registry:
$ docker images

REPOSITORY            TAG                 IMAGE ID
friendlyhello         latest              326387cea398
Tip: You can use the commands docker images or the newer docker image ls list images. They give you the same output.

Run the app

Run the app, mapping your machine’s port 4000 to the container’s published port 80 using -p:
docker run -p 4000:80 friendlyhello
You should see a message that Python is serving your app at http://0.0.0.0:80. But that message is coming from inside the container, which doesn’t know you mapped port 80 of that container to 4000, making the correct URL http://localhost:4000.
Go to that URL in a web browser to see the display content served up on a web page, including “Hello World” text, the container ID, and the Redis error message.
Hello World in browser
Note: If you are using Docker Toolbox on Windows 7, use the Docker Machine IP instead of localhost. For example, http://192.168.99.100:4000/. To find the IP address, use the command docker-machine ip.
You can also use the curl command in a shell to view the same content.
$ curl http://localhost:4000

<h3>Hello World!</h3><b>Hostname:</b> 8fc990912a14<br/><b>Visits:</b> <i>cannot connect to Redis, counter disabled</i>
This port remapping of 4000:80 is to demonstrate the difference between what you EXPOSE within the Dockerfile, and what you publish using docker run -p. In later steps, we’ll just map port 80 on the host to port 80 in the container and use http://localhost.
Hit CTRL+C in your terminal to quit.
On Windows, explicitly stop the container
On Windows systems, CTRL+C does not stop the container. So, first type CTRL+C to get the prompt back (or open another shell), then type docker container ls to list the running containers, followed by docker container stop <Container NAME or ID> to stop the container. Otherwise, you’ll get an error response from the daemon when you try to re-run the container in the next step.
Now let’s run the app in the background, in detached mode:
docker run -d -p 4000:80 friendlyhello
You get the long container ID for your app and then are kicked back to your terminal. Your container is running in the background. You can also see the abbreviated container ID with docker container ls (and both work interchangeably when running commands):
$ docker container ls
CONTAINER ID        IMAGE               COMMAND             CREATED
1fa4ab2cf395        friendlyhello       "python app.py"     28 seconds ago
You’ll see that CONTAINER ID matches what’s on http://localhost:4000.
Now use docker container stop to end the process, using the CONTAINER ID, like so:
docker container stop 1fa4ab2cf395

Share your image

To demonstrate the portability of what we just created, let’s upload our built image and run it somewhere else. After all, you’ll need to learn how to push to registries when you want to deploy containers to production.
A registry is a collection of repositories, and a repository is a collection of images—sort of like a GitHub repository, except the code is already built. An account on a registry can create many repositories. The docker CLI uses Docker’s public registry by default.
Note: We’ll be using Docker’s public registry here just because it’s free and pre-configured, but there are many public ones to choose from, and you can even set up your own private registry using Docker Trusted Registry.

Log in with your Docker ID

If you don’t have a Docker account, sign up for one at cloud.docker.com. Make note of your username.
Log in to the Docker public registry on your local machine.
$ docker login

Tag the image

The notation for associating a local image with a repository on a registry is username/repository:tag. The tag is optional, but recommended, since it is the mechanism that registries use to give Docker images a version. Give the repository and tag meaningful names for the context, such as get-started:part2. This will put the image in the get-started repository and tag it as part2.
Now, put it all together to tag the image. Run docker tag image with your username, repository, and tag names so that the image will upload to your desired destination. The syntax of the command is:
docker tag image username/repository:tag
For example:
docker tag friendlyhello john/get-started:part2
Run docker images to see your newly tagged image. (You can also use docker image ls.)
$ docker images
REPOSITORY               TAG                 IMAGE ID            CREATED             SIZE
friendlyhello            latest              d9e555c53008        3 minutes ago       195MB
john/get-started         part2               d9e555c53008        3 minutes ago       195MB
python                   2.7-slim            1c7128a655f6        5 days ago          183MB
...

Publish the image

Upload your tagged image to the repository:
docker push username/repository:tag
Once complete, the results of this upload are publicly available. If you log in to Docker Hub, you will see the new image there, with its pull command.

Pull and run the image from the remote repository

From now on, you can use docker run and run your app on any machine with this command:
docker run -p 4000:80 username/repository:tag
If the image isn’t available locally on the machine, Docker will pull it from the repository.
$ docker run -p 4000:80 john/get-started:part2
Unable to find image 'john/get-started:part2' locally
part2: Pulling from john/get-started
10a267c67f42: Already exists
f68a39a6a5e4: Already exists
9beaffc0cf19: Already exists
3c1fe835fb6b: Already exists
4c9f1fa8fcb8: Already exists
ee7d8f576a14: Already exists
fbccdcced46e: Already exists
Digest: sha256:0601c866aab2adcc6498200efd0f754037e909e5fd42069adeff72d1e2439068
Status: Downloaded newer image for john/get-started:part2
 * Running on http://0.0.0.0:80/ (Press CTRL+C to quit)
Note: If you don’t specify the :tag portion of these commands, the tag of :latest will be assumed, both when you build and when you run images. Docker will use the last version of the image that ran without a tag specified (not necessarily the most recent image).
No matter where docker run executes, it pulls your image, along with Python and all the dependencies from requirements.txt, and runs your code. It all travels together in a neat little package, and the host machine doesn’t have to install anything but Docker to run it.

Get Started, Part 3: Services

Estimated reading time: 8 minutes

Prerequisites

Introduction

In part 3, we scale our application and enable load-balancing. To do this, we must go one level up in the hierarchy of a distributed application: the service.
  • Stack
  • Services (you are here)
  • Container (covered in part 2)

About services

In a distributed application, different pieces of the app are called “services.” For example, if you imagine a video sharing site, it probably includes a service for storing application data in a database, a service for video transcoding in the background after a user uploads something, a service for the front-end, and so on.
Services are really just “containers in production.” A service only runs one image, but it codifies the way that image runs—what ports it should use, how many replicas of the container should run so the service has the capacity it needs, and so on. Scaling a service changes the number of container instances running that piece of software, assigning more computing resources to the service in the process.
Luckily it’s very easy to define, run, and scale services with the Docker platform – just write a docker-compose.yml file.

Your first docker-compose.yml file

docker-compose.yml file is a YAML file that defines how Docker containers should behave in production.

docker-compose.yml

Save this file as docker-compose.yml wherever you want. Be sure you have pushed the image you created in Part 2 to a registry, and update this .yml by replacing username/repo:tag with your image details.
version: "3"
services:
  web:
    # replace username/repo:tag with your name and image details
    image: username/repo:tag
    deploy:
      replicas: 5
      resources:
        limits:
          cpus: "0.1"
          memory: 50M
      restart_policy:
        condition: on-failure
    ports:
      - "80:80"
    networks:
      - webnet
networks:
  webnet:
This docker-compose.yml file tells Docker to do the following:
  • Pull the image we uploaded in step 2 from the registry.
  • Run 5 instances of that image as a service called web, limiting each one to use, at most, 10% of the CPU (across all cores), and 50MB of RAM.
  • Immediately restart containers if one fails.
  • Map port 80 on the host to web’s port 80.
  • Instruct web’s containers to share port 80 via a load-balanced network called webnet. (Internally, the containers themselves will publish to web’s port 80 at an ephemeral port.)
  • Define the webnet network with the default settings (which is a load-balanced overlay network).

Run your new load-balanced app

Before we can use the docker stack deploy command we’ll first run:
docker swarm init
Note: We’ll get into the meaning of that command in part 4. If you don’t run docker swarm init you’ll get an error that “this node is not a swarm manager.”
Now let’s run it. You have to give your app a name. Here, it is set to getstartedlab:
docker stack deploy -c docker-compose.yml getstartedlab
Our single service stack is running 5 container instances of our deployed image on one host. Let’s investigate.
Get the service ID for the one service in our application:
docker service ls
You’ll see output for the web service, prepended with your app name. If you named it the same as shown in this example, the name will be getstartedlab_web. The service ID is listed as well, along with the number of replicas, image name, and exposed ports.
A single container running in a service is called a task. Tasks are given unique IDs that numerically increment, up to the number of replicas you defined in docker-compose.yml. List the tasks for your service:
docker service ps getstartedlab_web
Tasks also show up if you just list all the containers on your system, though that will not be filtered by service:
docker container ls -q
You can run curl -4 http://localhost several times in a row, or go to that URL in your browser and hit refresh a few times.
Hello World in browser
Either way, you’ll see the container ID change, demonstrating the load-balancing; with each request, one of the 5 tasks is chosen, in a round-robin fashion, to respond. The container IDs will match your output from the previous command (docker container ls -q).
Running Windows 10?
Windows 10 PowerShell should already have curl available, but if not you can grab a Linux terminal emulater like Git BASH, or download wget for Windows which is very similar.
Slow response times?
Depending on your environment’s networking configuration, it may take up to 30 seconds for the containers to respond to HTTP requests. This is not indicative of Docker or swarm performance, but rather an unmet Redis dependency that we will address later in the tutorial. For now, the visitor counter isn’t working for the same reason; we haven’t yet added a service to persist data.

Scale the app

You can scale the app by changing the replicas value in docker-compose.yml, saving the change, and re-running the docker stack deploy command:
docker stack deploy -c docker-compose.yml getstartedlab
Docker will do an in-place update, no need to tear the stack down first or kill any containers.
Now, re-run docker container ls -q to see the deployed instances reconfigured. If you scaled up the replicas, more tasks, and hence, more containers, are started.

Take down the app and the swarm

  • Take the app down with docker stack rm:
    docker stack rm getstartedlab

  • Take down the swarm.
    docker swarm leave --force

It’s as easy as that to stand up and scale your app with Docker. You’ve taken a huge step towards learning how to run containers in production. Up next, you will learn how to run this app as a bonafide swarm on a cluster of Docker machines.
Note: Compose files like this are used to define applications with Docker, and can be uploaded to cloud providers using Docker Cloud, or on any hardware or cloud provider you choose with Docker Enterprise Edition.

Recap and cheat sheet (optional)

To recap, while typing docker run is simple enough, the true implementation of a container in production is running it as a service. Services codify a container’s behavior in a Compose file, and this file can be used to scale, limit, and redeploy our app. Changes to the service can be applied in place, as it runs, using the same command that launched the service: docker stack deploy.
Some commands to explore at this stage:
docker stack ls                                            # List stacks or apps
docker stack deploy -c <composefile> <appname>  # Run the specified Compose file
docker service ls                 # List running services associated with an app
docker service ps <service>                  # List tasks associated with an app
docker inspect <task or container>                   # Inspect task or container
docker container ls -q                                      # List container IDs
docker stack rm <appname>                             # Tear down an application
docker swarm leave --force      # Take down a single node swarm from the manager

Get Started, Part 4: Swarms

Estimated reading time: 18 minutes

Prerequisites

Introduction

In part 3, you took an app you wrote in part 2, and defined how it should run in production by turning it into a service, scaling it up 5x in the process.
Here in part 4, you deploy this application onto a cluster, running it on multiple machines. Multi-container, multi-machine applications are made possible by joining multiple machines into a “Dockerized” cluster called a swarm.

Understanding Swarm clusters

A swarm is a group of machines that are running Docker and joined into a cluster. After that has happened, you continue to run the Docker commands you’re used to, but now they are executed on a cluster by a swarm manager. The machines in a swarm can be physical or virtual. After joining a swarm, they are referred to as nodes.
Swarm managers can use several strategies to run containers, such as “emptiest node” – which fills the least utilized machines with containers. Or “global”, which ensures that each machine gets exactly one instance of the specified container. You instruct the swarm manager to use these strategies in the Compose file, just like the one you have already been using.
Swarm managers are the only machines in a swarm that can execute your commands, or authorize other machines to join the swarm as workers. Workers are just there to provide capacity and do not have the authority to tell any other machine what it can and cannot do.
Up until now, you have been using Docker in a single-host mode on your local machine. But Docker also can be switched into swarm mode, and that’s what enables the use of swarms. Enabling swarm mode instantly makes the current machine a swarm manager. From then on, Docker will run the commands you execute on the swarm you’re managing, rather than just on the current machine.

Set up your swarm

A swarm is made up of multiple nodes, which can be either physical or virtual machines. The basic concept is simple enough: run docker swarm init to enable swarm mode and make your current machine a swarm manager, then run docker swarm join on other machines to have them join the swarm as workers. Choose a tab below to see how this plays out in various contexts. We’ll use VMs to quickly create a two-machine cluster and turn it into a swarm.

Create a cluster

VMS ON YOUR LOCAL MACHINE (MAC, LINUX, WINDOWS 7 AND 8)

First, you’ll need a hypervisor that can create virtual machines (VMs), so install Oracle VirtualBox for your machine’s OS.
Note: If you are on a Windows system that has Hyper-V installed, such as Windows 10, there is no need to install VirtualBox and you should use Hyper-V instead. View the instructions for Hyper-V systems by clicking the Hyper-V tab above. If you are using Docker Toolbox, you should already have VirtualBox installed as part of it, so you are good to go.
Now, create a couple of VMs using docker-machine, using the VirtualBox driver:
docker-machine create --driver virtualbox myvm1
docker-machine create --driver virtualbox myvm2

LIST THE VMS AND GET THEIR IP ADDRESSES

You now have two VMs created, named myvm1 and myvm2.
Use this command to list the machines and get their IP addresses.
docker-machine ls
Here is example output from this command.
$ docker-machine ls
NAME    ACTIVE   DRIVER       STATE     URL                         SWARM   DOCKER        ERRORS
myvm1   -        virtualbox   Running   tcp://192.168.99.100:2376           v17.06.2-ce
myvm2   -        virtualbox   Running   tcp://192.168.99.101:2376           v17.06.2-ce

INITIALIZE THE SWARM AND ADD NODES

The first machine will act as the manager, which executes management commands and authenticates workers to join the swarm, and the second will be a worker.
You can send commands to your VMs using docker-machine ssh. Instruct myvm1 to become a swarm manager with docker swarm init and you’ll see output like this:
$ docker-machine ssh myvm1 "docker swarm init --advertise-addr <myvm1 ip>"
Swarm initialized: current node <node ID> is now a manager.

To add a worker to this swarm, run the following command:

  docker swarm join \
  --token <token> \
  <myvm ip>:<port>

To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions.
Ports 2377 and 2376
Always run docker swarm init and docker swarm join with port 2377 (the swarm management port), or no port at all and let it take the default.
The machine IP addresses returned by docker-machine ls include port 2376, which is the Docker daemon port. Do not use this port or you may experience errors.
As you can see, the response to docker swarm init contains a pre-configured docker swarm joincommand for you to run on any nodes you want to add. Copy this command, and send it to myvm2 via docker-machine ssh to have myvm2 join your new swarm as a worker:
$ docker-machine ssh myvm2 "docker swarm join \
--token <token> \
<ip>:2377"

This node joined a swarm as a worker.
Congratulations, you have created your first swarm!
Run docker node ls on the manager to view the nodes in this swarm:
$ docker-machine ssh myvm1 "docker node ls"
ID                            HOSTNAME            STATUS              AVAILABILITY        MANAGER STATUS
brtu9urxwfd5j0zrmkubhpkbd     myvm2               Ready               Active
rihwohkh3ph38fhillhhb84sk *   myvm1               Ready               Active              Leader
Leaving a swarm
If you want to start over, you can run docker swarm leave from each node.

Deploy your app on the swarm cluster

The hard part is over. Now you just repeat the process you used in part 3 to deploy on your new swarm. Just remember that only swarm managers like myvm1 execute Docker commands; workers are just for capacity.

Configure a docker-machine shell to the swarm manager

So far, you’ve been wrapping Docker commmands in docker-machine ssh to talk to the VMs. Another option is to run docker-machine env <machine> to get and run a command that configures your current shell to talk to the Docker daemon on the VM. This method works better for the next step because it allows you to use your local docker-compose.yml file to deploy the app “remotely” without having to copy it anywhere.
Type docker-machine env myvm1, then copy-paste and run the command provided as the last line of the output to configure your shell to talk to myvm1, the swarm manager.
The commands to configure your shell differ depending on whether you are Mac, Linux, or Windows, so examples of each are shown on the tabs below.

DOCKER MACHINE SHELL ENVIRONMENT ON MAC OR LINUX

Run docker-machine env myvm1 to get the command to configure your shell to talk to myvm1.
$ docker-machine env myvm1
export DOCKER_TLS_VERIFY="1"
export DOCKER_HOST="tcp://192.168.99.100:2376"
export DOCKER_CERT_PATH="/Users/sam/.docker/machine/machines/myvm1"
export DOCKER_MACHINE_NAME="myvm1"
# Run this command to configure your shell:
# eval $(docker-machine env myvm1)
Run the given command to configure your shell to talk to myvm1.
eval $(docker-machine env myvm1)
Run docker-machine ls to verify that myvm1 is now the active machine, as indicated by the asterisk next to it.
$ docker-machine ls
NAME    ACTIVE   DRIVER       STATE     URL                         SWARM   DOCKER        ERRORS
myvm1   *        virtualbox   Running   tcp://192.168.99.100:2376           v17.06.2-ce
myvm2   -        virtualbox   Running   tcp://192.168.99.101:2376           v17.06.2-ce

Deploy the app on the swarm manager

Now that you have my myvm1, you can use its powers as a swarm manager to deploy your app by using the same docker stack deploy command you used in part 3 to myvm1, and your local copy of docker-compose.yml.
You are connected to myvm1 by means of the docker-machine shell configuration, and you still have access to the files on your local host. Make sure you are in the same directory as before, which includes thedocker-compose.yml file you created in part 3.
Just like before, run the following command to deploy the app on myvm1.
docker stack deploy -c docker-compose.yml getstartedlab
And that’s it, the app is deployed on a swarm cluster!
Now you can use the same docker commands you used in part 3. Only this time you’ll see that the services (and associated containers) have been distributed between both myvm1 and myvm2.
$ docker stack ps getstartedlab

ID            NAME                  IMAGE                   NODE   DESIRED STATE
jq2g3qp8nzwx  getstartedlab_web.1   john/get-started:part2  myvm1  Running
88wgshobzoxl  getstartedlab_web.2   john/get-started:part2  myvm2  Running
vbb1qbkb0o2z  getstartedlab_web.3   john/get-started:part2  myvm2  Running
ghii74p9budx  getstartedlab_web.4   john/get-started:part2  myvm1  Running
0prmarhavs87  getstartedlab_web.5   john/get-started:part2  myvm2  Running
Connecting to VMs with docker-machine env and docker-machine ssh
  • To set your shell to talk to a different machine like myvm2, simply re-run docker-machine env in the same or a different shell, then run the given command to point to myvm2. This is always specific to the current shell. If you change to an unconfigured shell or open a new one, you need to re-run the commands. Use docker-machine ls to list machines, see what state they are in, get IP addresses, and find out which one, if any, you are connected to. To learn more, see the Docker Machine getting started topics.
  • Alternatively, you can wrap Docker commands in the form ofdocker-machine ssh <machine> "<command>", which logs directly into the VM but doesn’t give you immediate access to files on your local host.
  • On Mac and Linux, you can use docker-machine scp <file> <machine>:~ to copy files across machines, but Windows users need a Linux terminal emulator like Git Bash in order for this to work.
This tutorial demos both docker-machine ssh and docker-machine env, since these are available on all platforms via the docker-machine CLI.

Accessing your cluster

You can access your app from the IP address of either myvm1 or myvm2.
The network you created is shared between them and load-balancing. Run docker-machine ls to get your VMs’ IP addresses and visit either of them on a browser, hitting refresh (or just curl them).
Hello World in browser
You’ll see five possible container IDs all cycling by randomly, demonstrating the load-balancing.
The reason both IP addresses work is that nodes in a swarm participate in an ingress routing mesh. This ensures that a service deployed at a certain port within your swarm always has that port reserved to itself, no matter what node is actually running the container. Here’s a diagram of how a routing mesh for a service called my-web published at port 8080 on a three-node swarm would look:
routing mesh diagram
Having connectivity trouble?
Keep in mind that in order to use the ingress network in the swarm, you need to have the following ports open between the swarm nodes before you enable swarm mode:
  • Port 7946 TCP/UDP for container network discovery.
  • Port 4789 UDP for the container ingress network.

Iterating and scaling your app

From here you can do everything you learned about in parts 2 and 3.
Scale the app by changing the docker-compose.yml file.
Change the app behavior by editing code, then rebuild, and push the new image. (To do this, follow the same steps you took earlier to build the app and publish the image).
In either case, simply run docker stack deploy again to deploy these changes.
You can join any machine, physical or virtual, to this swarm, using the same docker swarm join command you used on myvm2, and capacity will be added to your cluster. Just run docker stack deploy afterwards, and your app will take advantage of the new resources.

Cleanup and reboot

Stacks and swarms

You can tear down the stack with docker stack rm. For example:
docker stack rm getstartedlab
Keep the swarm or remove it?
At some point later, you can remove this swarm if you want to withdocker-machine ssh myvm2 "docker swarm leave" on the worker and docker-machine ssh myvm1 "docker swarm leave --force" on the manager, but you’ll need this swarm for part 5, so please keep it around for now.

Unsetting docker-machine shell variable settings

You can unset the docker-machine environment variables in your current shell with the following command:
eval $(docker-machine env -u)
This disconnects the shell from docker-machine created virtual machines, and allows you to continue working in the same shell, now using native docker commands (for example, on Docker for Mac or Docker for Windows). To learn more, see the Machine topic on unsetting environment variables.

Restarting Docker machines

If you shut down your local host, Docker machines will stop running. You can check the status of machines by running docker-machine ls.
$ docker-machine ls
NAME    ACTIVE   DRIVER       STATE     URL   SWARM   DOCKER    ERRORS
myvm1   -        virtualbox   Stopped                 Unknown
myvm2   -        virtualbox   Stopped                 Unknown
To restart a machine that’s stopped, run:
docker-machine start <machine-name>
For example:
$ docker-machine start myvm1
Starting "myvm1"...
(myvm1) Check network to re-create if needed...
(myvm1) Waiting for an IP...
Machine "myvm1" was started.
Waiting for SSH to be available...
Detecting the provisioner...
Started machines may have new IP addresses. You may need to re-run the `docker-machine env` command.

$ docker-machine start myvm2
Starting "myvm2"...
(myvm2) Check network to re-create if needed...
(myvm2) Waiting for an IP...
Machine "myvm2" was started.
Waiting for SSH to be available...
Detecting the provisioner...
Started machines may have new IP addresses. You may need to re-run the `docker-machine env` command.

Recap and cheat sheet (optional)

In part 4 you learned what a swarm is, how nodes in swarms can be managers or workers, created a swarm, and deployed an application on it. You saw that the core Docker commands didn’t change from part 3, they just had to be targeted to run on a swarm master. You also saw the power of Docker’s networking in action, which kept load-balancing requests across containers, even though they were running on different machines. Finally, you learned how to iterate and scale your app on a cluster.
Here are some commands you might like to run to interact with your swarm and your VMs a bit:
docker-machine create --driver virtualbox myvm1 # Create a VM (Mac, Win7, Linux)
docker-machine create -d hyperv --hyperv-virtual-switch "myswitch" myvm1 # Win10
docker-machine env myvm1                # View basic information about your node
docker-machine ssh myvm1 "docker node ls"         # List the nodes in your swarm
docker-machine ssh myvm1 "docker node inspect <node ID>"        # Inspect a node
docker-machine ssh myvm1 "docker swarm join-token -q worker"   # View join token
docker-machine ssh myvm1   # Open an SSH session with the VM; type "exit" to end
docker node ls                # View nodes in swarm (while logged on to manager)
docker-machine ssh myvm2 "docker swarm leave"  # Make the worker leave the swarm
docker-machine ssh myvm1 "docker swarm leave -f" # Make master leave, kill swarm
docker-machine ls # list VMs, asterisk shows which VM this shell is talking to
docker-machine start myvm1            # Start a VM that is currently not running
docker-machine env myvm1      # show environment variables and command for myvm1
eval $(docker-machine env myvm1)         # Mac command to connect shell to myvm1
& "C:\Program Files\Docker\Docker\Resources\bin\docker-machine.exe" env myvm1 | Invoke-Expression   # Windows command to connect shell to myvm1
docker stack deploy -c <file> <app>  # Deploy an app; command shell must be set to talk to manager (myvm1), uses local Compose file
docker-machine scp docker-compose.yml myvm1:~ # Copy file to node's home dir (only required if you use ssh to connect to manager and deploy the app)
docker-machine ssh myvm1 "docker stack deploy -c <file> <app>"   # Deploy an app using ssh (you must have first copied the Compose file to myvm1)
eval $(docker-machine env -u)     # Disconnect shell from VMs, use native docker
docker-machine stop $(docker-machine ls -q)               # Stop all running VMs
docker-machine rm $(docker-machine ls -q) # Delete all VMs and their disk images
